Trailer Specifications:
| GVWR: | 9990 | Empty Weight: | 2800 |
| Payload: | 7190 | Axles: | 2 – 5.2K EZ Lube 6 Lug (1) Brake |
| Breakaway: | Standard with Brake | Bumprail: | 5” Channel |
| Coupler: | 2 5/16” 12.5K A-Frame Cast w/Pin | Crossmembers: | 18” Centers |
| D-Rings: | Fenders: | 10"X72” Teardrop Diamond Plate w/Lights – HD Drive Over 10 Ga w/ 10 Ga. Back | |
| Floor: | 2” Douglas Fir | Frame: | 6” Channel |
| Heavy Duty Frame: | 6” Channel Heavy | Jack: | 7K Dropleg |
| Lights: | LED Lights Grommet Mounted Sealed Beam in Box | Paint: | (2) Coats Single Stage |
| Plug & Wiring: | 7 Way Round, Modular, Rubber Sealed, Harness | Ramps: | 5’ 3” Channel Slide in (Rear) |
| Stake Pockets: | 4 in Front & 2 in Rear | Suspension: | |
| Tires: | ST225/75R15 LR (E) Radial | Tongue: | 4’ Tongue 5" Channel |
| Wheels: | 15” 6-5.5 Black Mod | Add Ons Included: | SPARE MOUNT & SPARE TIRE |
| GVWR: | 9990 |
| Empty Weight: | 2800 |
| Payload: | 7190 |
| Axles: | 2 – 5.2K EZ Lube 6 Lug (1) Brake |
| Breakaway: | Standard with Brake |
| Bumprail: | 5” Channel |
| Coupler: | 2 5/16” 12.5K A-Frame Cast w/Pin |
| Crossmembers: | 18” Centers |
| D-Rings: | |
| Fenders: | 10"X72” Teardrop Diamond Plate w/Lights – HD Drive Over 10 Ga w/ 10 Ga. Back |
| Floor: | 2” Douglas Fir |
| Frame: | 6” Channel |
| Heavy Duty Frame: | 6” Channel Heavy |
| Jack: | 7K Dropleg |
| Lights: | LED Lights Grommet Mounted Sealed Beam in Box |
| Paint: | (2) Coats Single Stage |
| Plug & Wiring: | 7 Way Round, Modular, Rubber Sealed, Harness |
| Ramps: | 5’ 3” Channel Slide in (Rear) |
| Stake Pockets: | 4 in Front & 2 in Rear |
| Suspension: | |
| Tires: | ST225/75R15 LR (E) Radial |
| Tongue: | 4’ Tongue 5" Channel |
| Wheels: | 15” 6-5.5 Black Mod |
| Add Ons Included: | SPARE MOUNT & SPARE TIRE |
